PROCAD ELECTRIC
What PROCAD ELECTRIC is
PROCAD ELECTRIC is Windows software for intelligent 2D drafting of electrical single-line diagrams, control schematics, and layout drawings. It includes electrical symbols and components such as capacitors, transformers, and relays, plus automation for preset line types, terminal blocks, wire tagging, and cable tray layouts. Standards Manager controls project units, symbol scaling, layers, colors, drawing borders, and dimensioning variables. Drawing libraries provide I/O card drawings for Allen Bradley, Siemens, and Square D, along with single- and three-phase lighting panel schedules for 6–42 circuits. PROCAD applications include built-in AutoCAD OEM and save drawings in DWG format; that OEM cannot be customized or used for other third-party add-ons. Requirements list 64-bit Windows 10 version 1803 or higher, or Windows 11. Licenses can be standalone node-locked or network concurrent, including VPN access through a company network. A 15-day trial is available. Plans include $60 a year for three-year prepaid, $71 a year for one-year prepaid, and $95 a month for monthly subscription.
Who it suits
PROCAD ELECTRIC suits electrical professionals creating diagrams, schematics, and layouts on supported Windows systems. It may fit teams choosing node-locked or network licenses and needing DWG-based drafting.
What it does well
- Electrical symbol and component library
- Automation for wiring tasks
- Configurable Standards Manager
- DWG drawing support
- Network licensing with VPN access
What to know first
- Windows only
- AutoCAD OEM cannot run add-ons
- No free plan
- Monthly plan costs $95 a month
Plans
PROCAD ELECTRIC's published prices are being re-checked against the maker's own page.
| Plan | Billed and limits | Price |
|---|---|---|
| ELECTRIC 3-Year Prepaid | One time billing · Starting at $1.96/day · 3-year prepaid license | Price being re-checked |
| ELECTRIC 1-Year Prepaid | One time billing · Starting at $2.34/day · 1-year prepaid license | Price being re-checked |
| ELECTRIC Monthly Subscription | Billed monthly · Starting at $3.17/day · Monthly subscription can be modified or canceled with 5-day advance notice | Price being re-checked |
As procad.com lists them, read 11 Oct 2026. The maker's own page has the final word.
Verdict
PROCAD ELECTRIC provides electrical drafting tools, configurable standards, drawing libraries, and DWG files on Windows. A 15-day trial and multiple license terms are available, but the built-in OEM limits customization and third-party add-ons.
Facts from PROCAD ELECTRIC's own pages
- Automation
- Automation tools include preset line types, terminal blocks, wire tagging, and cable tray layouts. · procad.com, 11 Oct 2026
- CAD and file format
- PROCAD applications include built-in AutoCAD OEM and save drawing files in DWG format. · procad.com, 11 Oct 2026
- Compatibility limit
- The built-in AutoCAD OEM cannot be customized or used to run other third-party add-on applications. · procad.com, 11 Oct 2026
- Drawing libraries
- ELECTRIC includes I/O card drawings for Allen Bradley, Siemens, and Square D, and single- and three-phase lighting panel schedules for 6–42 circuits. · procad.com, 11 Oct 2026
- License options
- PROCAD offers standalone node-locked and network concurrent licenses; a network license can be accessed by computers on the company network, including through VPN. · procad.com, 11 Oct 2026
- Maker location
- PROCAD describes itself as a Canadian-based company. · procad.com, 11 Oct 2026
- Operating system
- The listed system requirements specify 64-bit Windows 10 version 1803 or higher and Windows 11. · procad.com, 11 Oct 2026
- Privacy and data storage
- PROCAD says its web servers are hosted in Canada and customer communications are stored in Microsoft Dynamics CRM. · procad.com, 11 Oct 2026
- Purchase data
- PROCAD says credit card information for subscriptions or term licenses is stored by Elavon for record keeping and recurring payments. · procad.com, 11 Oct 2026
- Purpose
- ELECTRIC is intelligent 2D drafting software for electrical single-line diagrams, control schematics, and layout drawings. · procad.com, 11 Oct 2026
- Standards Manager
- The included Standards Manager lets users set project units, symbol scaling, layers, colors, drawing borders, and dimensioning variables. · procad.com, 11 Oct 2026
- Support
- PROCAD lists free same-day technical support by email, phone, or web meeting, along with tutorials, upgrades, and training credits. · procad.com, 11 Oct 2026
- Symbols and components
- It includes an electrical symbol and component library with items such as capacitors, transformers, and relays. · procad.com, 11 Oct 2026
