AFMG SysTune
What AFMG SysTune is
AFMG SysTune is Windows software for real-time and offline audio measurement and analysis in live sound, installed sound, and industry applications. It measures up to eight channels simultaneously, while SysTune Pro adds a channel matrix for more than eight channels. Supported signals include live sound, sweeps, pink noise, and user-defined signals. Views include impulse response, frequency response, phase response, group delay, real-time spectrogram, transfer function, SPL, LEQ, noise criteria, histograms, coherence, and IR stability. The software calculates RT and STI in real time. Standard provides virtual high-pass, low-pass, shelving, and four parametric filters; Pro adds 20 configurable IIR or FIR filters. A browser interface allows remote control over Wi-Fi from compatible mobile browsers. AFMG lists Windows Vista SP1 through Windows 11, plus at least 4 GB RAM, a 1.0 GHz processor, and a sound card or audio interface. Standard is €450.00 per once and Pro is €720.00 per once. A trial request is available.
Who it suits
Standard is aimed at live sound, audio engineering, installed sound, and development professionals. Pro is suited to laboratory measurements, loudspeaker development, building acoustics, and installed sound.
What it does well
- Real-time and offline file analysis
- Measures up to eight channels
- Broad measurement and analysis views
- Remote control through a browser interface
- Free trial request available
What to know first
- Windows platform only
- No free plan
- Standard is limited to eight channels
- No plugin support
Plans
| Plan | Billed and limits | Price |
|---|---|---|
| AFMG SysTune Standard | Full Licence Measurement Software · 1 User Key · 8 channels | €450, paid once |
| AFMG SysTune Pro | Full Licence Measurement Software · 1 User Key · channel matrix supports more than 8 channels | €720, paid once |
As afmg.eu lists them, read 9 Oct 2026. The maker's own page has the final word.
Verdict
SysTune offers extensive real-time and offline measurement views for Windows audio work, with Pro extending channel capacity and filter options. Its channel ceiling, platform requirement, and paid licensing should be checked against the intended setup.
Facts from AFMG SysTune's own pages
- Analysis features
- It displays impulse response, frequency response, phase response, group delay, and a real-time spectrogram, and calculates RT and STI in real time. · afmg.eu, 9 Oct 2026
- Hardware requirements
- AFMG lists 4 GB or more of RAM, a 1.0 GHz or faster processor, and a sound card or audio interface as requirements or recommendations. · afmg.eu, 9 Oct 2026
- Headquarters
- Berlin, Germany · afmg.eu, 28 Sept 2026
- Integrations
- SysTune offers an open plug-in API and lists integrations from manufacturers including d&b audiotechnik, Lake, and Linea Research. · afmg.eu, 9 Oct 2026
- Intended users
- AFMG describes Standard as intended for live sound, audio engineering, installed sound, and development professionals, and Pro as suited to laboratory measurements, loudspeaker development, building acoustics, and installed sound. · afmg.eu, 9 Oct 2026
- Measurement channels
- SysTune measures on up to eight channels simultaneously, and SysTune Pro adds a channel matrix for measurements using more than eight channels. · afmg.eu, 9 Oct 2026
- Measurement signals
- It supports live sound, sweeps, pink noise, and user-defined signals. · afmg.eu, 9 Oct 2026
- Measurement technology
- AFMG says SysTune uses its patented Real-Time Deconvolution algorithm to measure and process full-length impulse responses in real time. · afmg.eu, 9 Oct 2026
- Operating system
- AFMG lists Windows Vista SP1, Windows 7, Windows 8, Windows 10, and Windows 11 as supported operating systems. · afmg.eu, 9 Oct 2026
- Purpose
- SysTune performs real-time audio measurement and analysis for live sound, installed sound, and industry applications. · afmg.eu, 9 Oct 2026
- Remote control
- Its browser-based web interface lets users remotely control measurements over Wi-Fi from mobile devices whose browsers support SVG graphics. · afmg.eu, 9 Oct 2026
- Security and data handling
- AFMG's website privacy policy says website data is stored in the EU by hosting providers whose data centers are TÜV-certified to ISO 27001. · afmg.eu, 9 Oct 2026
- Support
- AFMG's SysTune license terms state that email and telephone technical support are provided for six months after purchase. · afmg.eu, 9 Oct 2026
- Trial
- AFMG provides a SysTune Trial Request page, but the opened page does not state a trial duration. · afmg.eu, 9 Oct 2026
- Virtual EQ
- Standard simulates high-pass, low-pass, shelving, and four parametric filters, while Pro adds 20 configurable IIR or FIR filters. · afmg.eu, 9 Oct 2026
