OpenCAD Studio
What OpenCAD Studio is
OpenCAD Studio is an open-source CAD application for 2D drafting, layouts and 3D modeling. It reads and writes DWG and DXF files natively, with save targets from R14 through R2018. Browser drafting includes command-line tools, layers, object snaps, dimensions, blocks, external references, layouts and viewports. 3D tools provide solid primitives plus extrusion, revolution, sweep, loft and Boolean operations. The browser version needs no account or installation, processes local drawings on the user’s machine and downloads saves to the device. Hosted Projects can store revisions and share revocable client links. Desktop builds for Windows, macOS and Linux add native plugins, system printing, PDF output, scripts and headless automation; the published macOS package supports Apple Silicon. The WebAssembly browser build runs sequentially, and the site recommends desktop for the largest drawings. Plans include Projects Free, OpenCAD Starter at $5.84 a month, OpenCAD Projects at $12.51 a month and free OpenCAD Studio CAD under GPL-3.0.
Who it suits
OpenCAD Studio suits people drafting or modeling across web and desktop environments with DWG or DXF files. Projects is useful for users needing stored revisions and revocable client links.
What it does well
- Native DWG and DXF support
- Browser use requires no account
- Includes 2D and 3D modeling tools
- Desktop adds plugins and automation
- 3D print export available
What to know first
- Browser build runs sequentially
- Largest drawings suit the desktop app
- Projects Free limits storage and links
- Some desktop features are unavailable online
Plans
| Plan | Billed and limits | Price |
|---|---|---|
| Projects Free | No card; no trial deadline · 1 private project · 3 saved revisions · 25 MB storage · files up to 10 MB · 1 active client link valid for 24 hours | Free |
| OpenCAD Starter | Billed monthly; cancel anytime · 5 private project folders · revision history within storage allowance · 500 MB storage · files up to 50 MB · 5 active client links with 1 or 7-day expiry | $5.84 a month |
| OpenCAD Projects | Billed monthly; cancel anytime · 100 private project folders · revision history within storage allowance · 5 GB storage · files up to 50 MB · 100 active client links with 1, 7 or 30-day expiry | $12.51 a month |
| OpenCAD Studio CAD | Free software under GPL-3.0 · Local DWG/DXF editing · no account required | Free |
As opencad.studio lists them, read 12 Oct 2026. The maker's own page has the final word.
Verdict
OpenCAD Studio covers drafting, layouts and solid modeling across browser and desktop builds. The free local CAD option is distinct from paid Projects storage and collaboration allowances.
Facts from OpenCAD Studio's own pages
- 3D modeling
- The application supports kernel-backed solid primitives, extrusion, revolution, sweep, loft and Boolean operations. · opencad.studio, 12 Oct 2026
- Browser limit
- The WebAssembly browser build runs sequentially, and the site says the desktop app is a better fit for the largest drawings. · opencad.studio, 12 Oct 2026
- Browser operation
- The browser build runs without an account or installation, processes local drawings on the user's machine, and downloads saves to the device. · opencad.studio, 12 Oct 2026
- Desktop-only features
- Native plugins, system printing, PDF output, scripts and headless automation require the desktop app. · opencad.studio, 12 Oct 2026
- Desktop platforms
- Desktop builds are available for Windows, macOS and Linux; the published macOS package supports Apple Silicon. · opencad.studio, 12 Oct 2026
- Drafting features
- The browser workspace includes command-line drafting, layers, object snaps, dimensions, blocks, external references, layouts and viewports. · opencad.studio, 12 Oct 2026
- File formats
- It reads and writes DWG and DXF natively, with save targets from R14 through R2018. · opencad.studio, 12 Oct 2026
- Free plan
- Yes · opencad.studio, 22 Sept 2026
- Integrations
- Projects supports email/password or Google sign-in, and Dodo Payments handles checkout, payment details, tax and billing records. · opencad.studio, 12 Oct 2026
- Maker
- The application is developed in the open by Hakan Seven and contributors. · opencad.studio, 12 Oct 2026
- Platform access
- both · opencad.studio, 22 Sept 2026
- 3D print export
- Yes · opencad.studio, 22 Sept 2026
- Privacy
- Private drawing files are stored separately and are accessible to the signed-in account unless the user creates a client link; private drawings are not submitted to AI services. · opencad.studio, 12 Oct 2026
- Project storage
- The hosted edition optionally connects to private Projects for saving revisions and sharing revocable client links. · opencad.studio, 12 Oct 2026
- Purpose
- OpenCADStudio is an open-source CAD application for 2D drafting, layouts and 3D modeling. · opencad.studio, 12 Oct 2026
- Support
- The upstream issue tracker handles application bugs and feature requests, while [email protected] handles site, Projects and billing questions. · opencad.studio, 12 Oct 2026
