What Kanapy is

Kanapy is a free Python package for generating three-dimensional synthetic polycrystalline microstructures from statistical grain and phase morphology data plus crystallographic texture information. It analyzes experimental EBSD maps, reconstructs crystallographic texture from measured orientations and misorientation distributions, and supports multiphase structures with explicitly defined matrix and dispersed phases. A hexahedral mesh generator represents complex microstructures as voxels for finite-element simulations. Kanapy can create spherical particle position and radius files for Neper, input files for Abaqus and other finite-element packages, and voxel structures exchanged through the modular materials data schema. Users access it through a Python API and command-line tools; the alpha-version GUI remains under development. Installation is documented through conda-forge or pip in a Python environment. Listed dependencies include NumPy, SciPy, Matplotlib, orix, NetworkX, and scikit-image. Texture functions additionally require MATLAB and MTEX installed separately. Linux, macOS, and Windows are supported; Linux and macOS require a working C/C++ compiler, while Windows uses a pre-built wheel. The project targets research and industry microstructure generation.

Who it suits

Kanapy suits researchers and engineers generating synthetic microstructures for finite-element simulations and related research or industry work. It fits users comfortable with Python, command-line tools, and the listed scientific dependencies.

What it does well

Generates three-dimensional synthetic polycrystalline microstructures
Analyzes EBSD morphology and crystallographic texture
Supports explicitly defined matrix and dispersed phases
Exports files for Neper and Abaqus workflows
Provides Python API and command-line access

What to know first

Alpha GUI is still under development
Texture module requires MATLAB and MTEX separately
Linux and macOS require a C/C++ compiler
Depends on several scientific Python packages

Verdict

Kanapy provides an open package for statistically and experimentally informed microstructure generation, analysis, and meshing. Its integrations and platform support are useful, but setup involves scientific dependencies and compiler requirements.

Facts from Kanapy's own pages

Abaqus integration: Kanapy can generate input files for Abaqus. · mrgprasad.github.io, 12 Oct 2026
Access: Kanapy provides a Python API and command-line tools; its alpha-version GUI is still under development. · github.com, 12 Oct 2026
Analysis: Kanapy analyzes experimental EBSD maps for microstructure morphology and texture. · github.com, 12 Oct 2026
Data exchange: Kanapy imports and exports voxel structures using the modular materials data schema. · github.com, 12 Oct 2026
Dependencies: The listed dependencies include NumPy, SciPy, Matplotlib, orix, NetworkX, and scikit-image. · github.com, 12 Oct 2026
Free plan: Yes · mrgprasad.github.io, 24 Sept 2026
Grain modeling: Kanapy reconstructs orientation distribution functions from experimental orientations and assigns orientations based on measured misorientation distributions. · mrgprasad.github.io, 12 Oct 2026
Installation: The project documents installation through conda-forge or pip in a Python environment. · github.com, 12 Oct 2026
Integrations: Kanapy can produce particle position and radius files for Neper and input files for finite-element packages. · github.com, 12 Oct 2026
Intended use: It is designed to generate synthetic microstructures for finite element simulations and research and industry use. · mrgprasad.github.io, 12 Oct 2026
Intended users: The project describes its goal as building a synthetic microstructure generation tool for research and industry use. · github.com, 12 Oct 2026
Interface: The documentation describes a command line interface for Kanapy. · mrgprasad.github.io, 12 Oct 2026
License: Kanapy is made available under the GNU AGPLv3 license. · mrgprasad.github.io, 12 Oct 2026
Mesh generation: It includes a hexahedral mesh generator for complex polycrystalline microstructures. · mrgprasad.github.io, 12 Oct 2026
Multiphase support: Kanapy supports multiphase microstructures, including explicitly defined matrix and dispersed phases. · github.com, 12 Oct 2026
Neper integration: Kanapy can generate spherical particle position and radius files that Neper can read. · mrgprasad.github.io, 12 Oct 2026
Performance implementation: The geometry module’s performance-critical component is implemented in C++ and accessed through Python bindings. · mrgprasad.github.io, 12 Oct 2026
Platform access: desktop · mrgprasad.github.io, 24 Sept 2026
Platform requirements: The documentation describes Linux, macOS, and Windows support; Linux and macOS require a working C/C++ compiler, while Windows installation uses a pre-built wheel. · mrgprasad.github.io, 12 Oct 2026
Purpose: Kanapy is a Python package for generating complex synthetic polycrystalline microstructures. · mrgprasad.github.io, 12 Oct 2026
Texture dependencies: The texture module uses MATLAB and MTEX, which the documentation says must be installed separately. · mrgprasad.github.io, 12 Oct 2026
Texture features: Kanapy reconstructs crystallographic texture from experimental orientations and assigns orientations based on measured misorientation distributions. · github.com, 12 Oct 2026
